| SCANNER TYPE |
Sheet Feed, one pass duplex A4 colour scanner |
| OPTICAL RESOLUTION |
600 x 600 dpi |
| MAXIMUM INTERPOLATED RESOLUTION |
1200 dpi |
| LIGHT SOURCE |
3 Colour RGB LED |
|
COLOUR SCAN MODE (Output bit depth)
|
30-bit input / 24-bit output |
GREYSCALE SCAN MODE (Output bit depth) |
30-bit input / 24-bit output |
| PAPER / MEDIA HANDLING |
|
| DOCUMENT SIZE |
Plastic card (in portrait scanning only), A4, A5, A6, B5, Business card, Letter, and Legal
A3 size supported by digital stitching
ADF Minimum size: 50.8mm x 50.8mm (Horizontal x Vertical)
ADF Maximum size: 215.9mm x 6096mm (Horizontal x Vertical)
|
| INPUT TRAY CAPACITY |
50 sheets (Based on 75g/m2 paper) |
| DAILY DUTY CYCLE |
4,000 pages |
| PAPER WEIGHT |
27-413 g/m2 |
| SCANNING SPEED |
|
| (A4/Letter Size) |
35ppm/70ipm : 200dpi – Black & White, Colour, Grey
35ppm/70ipm : 300dpi – Black & White, Colour, Grey
35ppm/70ipm : 400dpi – Black & White, Grey
|
| FUNCTIONS |
|
| DOCUMENT ENHANCEMENT TOOLS |
Skip blank page, A3 stitching, Punch holes removal, Automatic de-skew, Automatic multidocument recognition, Dual Image Output (Windows only), Auto-rotation, Text enhancement, Unsharp Mask (USM), Descreening, Automatic Folder Creation, Barcode Recognition, Full Zonal OCR
|
| OUTPUT FORMATS |
JPEG, TIFF, multi-TIFF, PDF, searchable PDF, secure PDF, PDF/A |
| BUNDLED SOFTWARE |
Epson Document Capture (Mac only), Epson Document Capture Pro (Windows only), Epson Scan 2 |
| SUPPORTED PLATFORMS |
Mac OS 11.0.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Mac OS X, Mac OS X 10.6.8, Windows 11, Windows 10, Windows 7, Windows 7 x64, Windows 8, Windows 8 (32/64 bit), Windows 8 RT, Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Server 2012 (64bit), Windows Server 2012 R2, Windows Vista, Windows Vista x64, Windows server 2003 R2, XP Professional x64 Edition |
| INTERFACE |
USB 3.0 |
| ENVIRONMENTAL CONDITIONS |
|
| TEMPERATURE |
Temperature (Operating): 41° to 95°F (5° to 35°C)
Storage: -13° to 140°F (-25° to 60°C) Humidity (Operating): 15 – 80% (no condensation)
|
| ELECTRICAL SPECIFICATIONS |
|
| RATED VOLTAGE |
AC 100-240V |
| POWER CONSUMPTION |
Operating: 17W
Ready mode: 9.2W
Sleep mode: 1.2W
Power Off: 0.1W
|
| DIMENSIONS |
|
| WIDTH x DEPTH x HEIGHT |
296mm x 169mm x 176mm |
| WEIGHT |
Approx. 3.7kg |
| WHAT'S IN THE BOX |
|
| Contents |
Epson WorkForce DS-530II, Setup Sheet, Warranty / Registration Card, USB Cable, Software CD-ROM, AC Adapter & Cable |
| PRODUCT OPTIONS |
|
| B12B819011 |
Flatbed Scanner Dock |
| B12B819031 |
Roller Assembly kit to suit |
| B12B819051 |
Carrier Sheet |
| B12B819291 |
Cleaning Kit |
| WARRANTY |
|
| Standard |
12 months return to base |
| Optional |
Additional 2 Year Warranty 3YWDS530II CoverPlus |
